4233 Series 33:1


The 4233 33:1 spray system is compact and lightweight with more than enough volume for one painter. The 4233 system is complete and ready-to-go to tackle your most demanding painting job. The 4233 is designed to be used with light to medium viscosity coatings such as stains, lacquers, varnished, sealers, latex and oil based enamels and other finishing materials. Complete systems include: 1/4” x 50’ airless spray hose, spray gun with reversible tip and guard, regulator, air filter / moisture separator, in-line lubricator and cart.

Specifications:

Maximum tip size ......................... .019 tip
Delivery ................................. .43 gpm
Fluid pressure ........................... 3,829 psi
Maximum inlet air pressure ............... 116 psi
Weight ................................... 60 lbs.

Request Quote


6530 Series 30:1

The 6530 30:1 spray system is compact and lightweight with enough volume for one painter. The 6530 system is complete and ready-to-go to tackle your most demanding painting job. The 6530 is designed to be used with medium viscosity architectural and protective coatings. Complete systems include: 1/4” x 50’ airless spray hose, spray gun with reversible tip and guard, regulator, air filter / moisture separator, in-line lubricator and a heavy duty cart.

Specifications:

Maximum tip size ........................ .023 tip
Delivery ................................. .67 gpm
Fluid pressure .......................... 3,528 psi
Maximum inlet air pressure .............. 116 psi
Weight .................................. 80 lbs.

Request Quote


2824 Series 64:1

The 2824 64:1 spray system is a heavy duty unit with enough volume to support 1 to 3 painters. The 2824 system is complete and ready-to-go to tackle your most demanding painting job. The 2824 64:1 spray system is also packed with enough pressure and volume to handle the harder-to-atomize coatings such as sprayable mastics, urethanes, and bonding cements. Complete systems include: 1/4” x 50’ airless spray hose, spray gun with reversible tip and guard, regulator, air filter / moisture separator, in-line lubricator and a heavy duty cart.

Specifications:

Tip size ............................. 1 gun to .047 tip
2 guns to .033 tip
3 guns to .027 tip
Delivery ............................. 2.4 gpm
Fluid pressure ...................... 6,586 psi
Maximum inlet air pressure .......... 116 psi
Weight .............................. 235 lbs.
